Fiber Optic Outdoor Cables

Ribbon Cable-200 Flow

Ribbon Cable-200 Flow

Ribbon fiber cable’s extreme density revolutionized the installation process. But with data demand soaring, new advances are needed. Our MiniXtend® Ribbon Cable - 200 Flow provides a 60%* reduction in OD while reducing cable prep time by 30%

Corning’s MiniXtend Cable with Flow Ribbon Technology is designed for microduct applications. Although typically installed via jetting the cable, it can also be pulled into conduits at the rated loads specified, allowing for a myriad of backbone duct applications. The cable construction leverages Corning’s Flow Ribbon Technology in a centralized design in order to minimize cable diameter, allowing for smaller duct utilization. The microducts can be placed in new construction pathways or be used to “override” existing cables to avoid cost of new pathway construction.

*60%: compared to existing 288 SST-UltraRibbon™ cable (250 µm flat ribbon). 30%: Routable subunits require no furcation.

Learn more about MiniXtend Ribbon
Cable-200 Flow

Learn more about MiniXtend Ribbon
Cable-200 Flow

Explore Possibilities with Flow Ribbon Technology
Features Benefits Value
SMF-28® Contour Fiber, 190 μm Diameter Improved bend performance. ITU-T G.657.A1 and G.657.A2 options available, MFD of 9.2 μm maintains full compatibility with existing fiber networks Provides a platform for density and reduced errors in installation and operation
Flow Ribbon Technology 200 µm pitched ribbon allows for both 200 µm and 250 µm splicer compatibility Compatible with existing 250 µm splicer ecosystem, along with new 200 µm splicer technology
Reduced Cable Diameter Up to 60% reduction in cable diameter (compared to existing SST-UltraRibbon™) Doubling fiber count per duct at similar ODs
Indoor/Outdoor Rated Cable Dual flame rated cable [CPR/LSZH (EMEA) and Riser (NA)] allows for single global cable solution, Eliminates need for transition splice at building entry Reduction of procurement and inventory complexity by 50%. Lower installation cost and reduced installation time
Thin-Film Subunits (TSU) Routable subunits require no furcation  Reduce cable prep time by 30%

View additional Standard Recommended Procedures for 288F and 864F here.
