Smaller, lighter and cost effective: the ideal solution for Distributed Tap networks
The Corning BPEO-CT Multiport Terminal is part of the new generation of optical connectivity designed and produced to meet the requirements and best practices of the Carriers in the Caribbean and Latin America region.
Due to its design with up to 10 OptiTap® connector ports and the capacity to accommodate up to two optical splitters, (one of it with asymmetric split ratio) it is the ideal terminal for Distributed Tap or cascaded networks.
| Features | Benefits |
|---|---|
| OptiTap® connector ports for all entries | Reduces installation failures and increases deployment speed |
| Volume 55% smaller than the UCAO MS Terminal | Easy installation and faster project approvals |
| Ports arranged in two rows with optimized spacing | Easy access to all connector ports |
| IP68 protection, permanently sealed | Suitable for underground and aerial applications |
| Wide area for identification | Meets operators' field identification standards |
| Connectors identified by colors and embossed numbers | Easy identinfication of entry and exit ports |
The BPEO CT Multiport terminal with 10P is equipped with one 1x2 asymmetric/uneven splitter, which feeds the pass-through port that feeds the subsequent terminals, for network continuity. It also has a 1x8 splitter that feeds the 8 subscriber connection ports
The BPEO CT Multiport terminal with 9P is equipped with a single 1x8 splitter for subscriber connection, designed to be used as the last terminal on the chain.
